Vacuum lifters MICKEY 155, MICKEY 255 and E-MICKEY 255
Most popular vacuum lifters for concrete slabs up to 255 kg
Faster laying of concrete slabs, less worker fatigue, and time savings on the construction site. MICKEY 155, MICKEY 255, and the battery-powered E-MICKEY 255 are vacuum lifters designed for everyday paving work.
Technical specifications
- Maximum load: 155/255 kg
- Device Weight: from 16 kg
- Power source: 230V or battery
- Vacuum: - 0.2 Bar
- Turbine Efficiency: 162 m3/h
- Warranty: 12 months (option to extend up to 36 months)
Available components
Select a component to see details
-
Suction cup (MICKEY) 40×40, max 100 kg
-
Suction cup (MICKEY) 90×10, max 55 kg
-
Chains for connecting the suction cups
-
Suction cup 35×90
-
Suction cup 50×65
We'll find the right equipment for your material
Provide the specification of the material you're lifting and we'll find the right equipment.
Key advantages
Faster installation pace
The gripper attaches to the element in about 1 second, allowing smooth handling and precise placement of slabs in their final position. Result: shorter project completion time and higher crew efficiency.
Joint‑free and precise installation – even next to façades
Top‑side gripping keeps all side edges of the element unobstructed. Slabs can be laid edge‑to‑edge and directly next to the building façade – thanks to tapered handles. Result: no need for manual shifting, straps or makeshift lifting methods.
Reduced strain on workers
MICKEY eliminates manual lifting of heavy elements, working on knees and constant bending. Result: reduced strain on the spine, knees and joints, and significantly improved work safety.
No damage
The safe vacuum grip does not damage the material or chip slab edges. Result: fewer costs and fewer customer complaints.
Easy removal of installed slabs
MICKEY allows quick removal of an already installed slab, e.g. to level the base or replace a cracked slab – even those placed tightly between others. Result: faster, more convenient work without improvising.
Enhanced company prestige
Using vacuum lifters increases your company’s professionalism and reputation among investors, clients and employees. Result: you gain a competitive advantage as a true professional.
MICKEY 155, MICKEY 255 or E-MICKEY 255 – which one to choose?
| Feature | MICKEY155 | MICKEY 255 | E-MICKEY 255 |
| Power supply | 230 V mains or generator | replaceable lithium-ion battery 60 V, 600Wh (Li-ion) | |
| Cordless operation | No | Yes | |
| Working time | continuous operation (mains-powered) | approx. 2 hours on a single battery* |
| Control Suction cup replacemen | Buttons on the machine or via radio remote control tool-free, using screw-on wing nuts |
